Eurocase EA200LED 750VA LINE INTERACTIVE UPS
Eurocase EA200LED 750VA LINE INTERACTIVE UPS
The Eurocase EA200LED 750 VA LINE INTERACTIVE UPS backup power supply uses Line Interactive topology, which actively stabilises the input voltage without switching to battery. The unit provides an apparent power of 750VA and a real power of 420W, which is sufficient for powering standard setups and office electronics. At a full load of 420W, it powers connected devices for 60 minutes, while at 100W, the backup time is 15 minutes. The efficiency at half load is 70%.
Key features of the Eurocase EA200LED 750 VA, LINE INTERACTIVE UPS backup power supply
- Line Interactive topology adjusts voltage without using the battery
- The output voltage has a modified sinewave form when running on battery
- The USB interface connects to a computer for power management
- Integrated protection shields the telephone line from voltage spikes
- Compact tower design makes it easy to place in an office or home
Connectivity and sockets
The Eurocase EA200LED 750 VA LINE INTERACTIVE UPS backup power supply uses a USB port and the included management software to communicate with a computer. The output voltage has a modified sinewave form, suitable for powering devices with switched-mode power supplies. The surge protection integrates protection not only for powered appliances but also for the telephone network via RJ-11 connectors. Its compact Tower design makes it easy to position. It offers two Schuko output sockets for connecting appliances. Input power is supplied by a standard 230V AC power cable.
Technical specification
- Ports: 2× Schuko output socket, 1× USB port, 2× RJ-11
- Protection: Surge protection, telephone network protection
- Operating modes: Line Interactive
- Operating temperature: 0–40°C
Specifications
Performance
Efficiency
Backup time
Power outlet type
Output type
Features
Dimensions
Weight
| Code: | COMPaaa0231 |
| Warranty: | 24 months |
