QNAP ES1686dc-R2-2142IT-96G
568,390,-
QNAP ES1686dc-R2-2142IT-96G
Do you want to optimize the way you store data? If so, you ought to consider the QNAP ES1686dc-R2-2142IT-96G data storage.. With all 16 slots, this device is able to store up to 402,65 TB. This is ample space for a massive amount of files in HD or 4K. Your data will be protected by RAID 0, RAID 1 (reflection), RAID 5, RAID 6, RAID 10 (1+0), RAID 50 (5+0) and RAID 60 (6+0) technology.
QNAP ES1686dc-R2-2142IT-96G Data Storage Key Features
- Read speed of: 5773 MB/s
- Write speed of 2201 MB/s
- QNAP nas dimensions are 483 × 132 × 630,6 mm
- RAID 0, RAID 1 (reflection), RAID 5, RAID 6, RAID 10 (1+0), RAID 50 (5+0) and RAID 60 (6+0)
Whole description
Specifications
Power outlet type
Country
Czechia, Slovakia, Hungary, Germany, Russia, Austria, Croatia, France, Poland, Romania, Slovenia
Use
Use
Company
Design
Rack
Storage
Maximum capacity
402.65 TB
Drive configuration
Disc-free
Number of drive bays (2.5" and 3.5")
16 ×
RAID supported
RAID 0, RAID 1 (reflection), RAID 5, RAID 6, RAID 10 (1+0), RAID 50 (5+0), RAID 60 (6+0)
Performance
System memory (RAM)
96 GB (98,304 MB)
Memory type
DDR4
RAM memory expandable to
512 GB (524,288 MB)
Number of RAM memory slots
8 ×
Number of populated memory slots
8 ×
Processor frequency
1.9 GHz
Read Speed
5,773 MB/s
Write speed
2,201 MB/s
CPU architecture
x86
Supported disks
Compatible disc type
2.5" SAS SSD, 2.5" SAS HDD, 3.5" SAS HDD
Software and services
Supported services
File Sharing (SAMBA, HFS, CIFS), Cloud server, Recording from IP cameras, FTP server, Web server, Download server, iSCSI, Database server
Power Supply
Power supply type
Internal
Power supply output
1,400 W
Interface
LAN
14 ×
PCIe
4 ×
Features and functions
Features
External storage expandability, PCIe card expansion
Functions
Equalizer, SSD cache acceleration, Virtualization, Redundant power supply (RPS)
Max. operating temperature
40 °C
Minimum operating temperature
0 °C
Consumption
Annual energy consumption
4,389 kWh
Dimensions and weight
Depth
630.6 mm
Height
132 mm
Width
483 mm
Weight
30.3 kg
Package contents
Package contents
Main unit, Power cable, RJ-45 network cable, Manual
Warranty
Extended warranty
Extended Warranty
All parameters
| Code: | Qnap25004 |
| Warranty: | 24 months |
| Links: | Producer's Website: |
| Manufacturer information |
QNAP GmbH, Karl-Arnold-Straße 26, 47877 Willich, +492154884280, [email protected]
|
