Assembly
Placement
Wall-mounted
Recommended installation height
100 cm
Minimum wall thickness
430 mm
Maximum wall thickness
430 mm
Efficiency
Efficiency
68 %
Minimum air flow
25 m3/h
Maximum air flow
45 m3/h
Features
Functions
Winter mode, AUTO mode, Ventilation mode
Sensor
temperature
Features
Counterflow heat exchanger, Overload protection, Continuous operation
Heat exchanger material
Plastic
Minimum operating temperature
0 °C
Maximum operating temperature
40 °C
Minimum Noise
22 dB(A)
Maximum loudness
39 dB(A)
Control
Control
No control options
Dimensions
Installation hole
100 mm
Electricity consumption
Max. power
6 W
