Power outlet type
Country
Czechia, Slovakia, Hungary, Austria, Poland
Type
Switch type
Centrally controlled by controller
Design
Rack
Use
Company, Camera systems
Functions
Functions
PoE
Switching layer
L3
Advanced network functions
QoS (Quality of Service), VLAN, Static line aggregation, Q-in-Q, LACP line aggregation
Management and security
802.1X authentication, ACL
Ports
RJ-45
48 ×
SFP+
4 ×
10/100/1000Base-T
48
LAN port transmission speed
Number of LAN ports with 1 Gbit speed
48
Number of LAN ports with 10 Gbit speed
4
PoE properties
PoE standard
802.3af (PoE), 802.3at (PoE+)
Performance
500 W
Maximum output power per port
30 W
Number of PoE ports
48 ×
Routing
Features
Power Supply
From the network
Maximum number of VLANs
4,096 ×
Features
IPv6 Ready
Speed
Switching capacity
176 Gb/s
Packet capacity (64B packets, in million of packets)
130.9 Mpps
Dimensions
Width
440 mm
Height
44 mm
Depth
440 mm
Material
Body material
Metal
Operating temperature
Maximum operating temperature
40 °C
Weight
Weight
5,410 g
