Chainway C61, 2D imager, Android 13
Chainway C61, 2D imager, Android 13
The Chainway C61 is a rugged mobile terminal designed for data collection in logistics, warehousing, manufacturing, retail and other operations. The device runs on the Android 13 operating system and a Qualcomm octa-core processor with a frequency of 1.8GHz. The terminal supports both numeric and QWERTY keyboards, dual-band Wi-Fi, 4G communication and advanced data collection technologies. This configuration includes an integrated 2D scanning module for capturing barcodes, with support for NFC and optional UHF RFID technology also available. It features a 4” multi-touch display that can be operated with gloves and wet hands. The display and side buttons are backlit for comfortable use in various lighting conditions. The device is equipped with a 13Mpx rear camera, a Micro SD memory card slot, a gravity sensor, a proximity sensor, a light sensor, an accelerometer and a vibration motor. It includes a removable 6700mAh battery with QC3.0 fast charging support.
Key features of the Chainway C61 mobile terminal, 2D imager, Android 13
- Android 13 operating system
- Qualcomm Octa-Core 1.8GHz processor
- Removable 6700mAh Li-Ion battery
- QC3.0 fast charging support
- IP65 rating according to IEC specifications
- Drop-resistant from a height of 1.8m
- Supports numeric and QWERTY keyboards
- Dual-band Wi-Fi 2.4GHz / 5GHz
- 13Mpx rear camera
- Four-inch multi-touch display
Durability for operational deployment
The Chainway C61 terminal has an industrial IP65 rating according to IEC specifications. The device withstands repeated drops from a height of 1.8m onto concrete across its entire operating temperature range. The design also meets the requirement for 1000 drops from a height of 0.5m at room temperature. The terminal is designed for operation at temperatures from -20°C to 50°C. Its durability is complemented by ESD protection of ±15kV air and ±8kV contact.
Advanced data collection options
The device is equipped with a 2D scanning module for capturing barcodes. The terminal also supports NFC communication at a frequency of 13.56MHz with support for ISO14443A/B, ISO15693, NFC-IP1 and NFC-IP2 protocols. The optional UHF RFID technology uses a CM710-1 module based on the Impinj E710 chip. The RFID part supports the EPC C1 GEN2 / ISO18000-6C protocol. The read rate exceeds 900 tags per second.
Performance, connectivity and power of the Chainway C61 mobile terminal
The device's performance is driven by a Qualcomm Octa-Core 1.8GHz processor combined with a memory configuration of 3GB RAM and 32GB storage or 4GB RAM and 64GB storage. Communication features include 4G networks, 802.11 a/b/g/n/ac Wi-Fi standards and Bluetooth 5.1. For positioning, GPS, AGPS, GLONASS, BeiDou and Galileo systems are supported. Charging time is 2.5 hours using the standard adapter and USB cable. Continuous use exceeds 12 hours, depending on operating conditions. The terminal is equipped with a 4” display with a resolution of 800×480 pixels.
Specifications
Display and batteries
Features
Memory
Performance
Environmental properties
Dimensions and weight
| Code: | CHAIter17 |
| Warranty: | 24 months |
