Type
Type
Clamp
Features
Features
Automatic shutdown, Battery indication, Overload protection, Audible signal, Automatic measurement range, Overrange indication
Standard
IEC 61010, CE
Measurement category
CAT II
Measurement function
Measurement function
AC voltage, DC voltage, Resistance, Diode, Continuity (buzzer), AC current
Direct voltage (DC)
Min. DC voltage
200 mV
Max. DC voltage
600 V
Accuracy ±
0.8 %
Alternating voltage (AC)
Min. AC voltage
2,000 mV
Max. AC voltage
600 V
Accuracy ±
1.2 %
Alternating current (AC)
Min. AC current
2,000,000 µA
Max. AC current
600 A
Accuracy ±
2.5 %
Electrical resistance
Min. resistance
200 ?
Max. resistance
20 M?
Accuracy ±
1 %
Dimensions
Height
190 mm
Width
76 mm
Depth
36 mm
Pliers diameter
25 mm
Weight
160 g
