Type
Type
Digital
Features
Features
Automatic shutdown, Backlit display, Battery indication, Overload protection, Audible signal, Data hold, Automatic measurement range, Overrange indication
Standard
IEC 61010, CE
Measurement category
CAT II
Measurement function
Measurement function
AC voltage, DC voltage, DC current, Resistance, Temperature, Diode, Continuity (buzzer), Capacity
Direct voltage (DC)
Min. DC voltage
200 mV
Max. DC voltage
300 V
Accuracy ±
0.8 %
Alternating voltage (AC)
Min. AC voltage
2,000 mV
Max. AC voltage
300 V
Accuracy ±
1 %
Direct current (DC)
Min. DC current
200 µA
Max. DC current
10 A
Accuracy ±
1.2 %
Alternating current (AC)
Min. AC current
200 µA
Max. AC current
10 A
Accuracy ±
1.5 %
Electrical resistance
Min. resistance
200 ?
Max. resistance
20 M?
Accuracy ±
1 %
Temperature
Min. temperature
-20 °C
Max. temperature
1,000 °C
Capacity
Min. capacity
20 nF
Max. capacity
1 mF
Accuracy ±
5 %
Dimensions
Height
158 mm
Width
75 mm
Depth
35 mm
Weight
200 g
