Type
Switch type
Centrally controlled by controller
Design
Desktop
Use
Company
Functions
Functions
Port mirroring
Switching layer
L2, L3, L4
Advanced network functions
QoS (Quality of Service), VLAN, Static line aggregation, Q-in-Q, LACP line aggregation
Management and security
DoS prevention, Port Security, ACL
Ports
RJ-45
8 ×
SFP
2 ×
10/100/1000Base-T
8
LAN port transmission speed
Number of LAN ports with 1 Gbit speed
1
Routing
Features
Power Supply
From the network
Maximum number of VLANs
4,096 ×
Features
IPv6 Ready
Speed
Switching capacity
20 Gb/s
Packet capacity (64B packets, in million of packets)
14.89 Mpps
Dimensions
Width
294 mm
Height
44 mm
Depth
180 mm
Material
Body material
Metal
Operating temperature
Maximum operating temperature
45 °C
