Type
Switch type
Managed
Use
Company
Functions
Functions
PoE
Switching layer
L2, L3
Advanced network functions
VLAN, VPN, LACP line aggregation
Management and security
ACL
Functions for camera systems
PoE Auto recovery
Ports
RJ-45
16 ×
SFP
2 ×
LAN port transmission speed
Number of LAN ports with 1 Gbit speed
16
Number of LAN ports with 10 Gbit speed
2
PoE properties
PoE standard
802.3af (PoE), 802.3at (PoE+)
Performance
0 W
Maximum output power per port
30 W
Number of PoE ports
16 ×
Routing
Routing
Static routing, RIP, OSPF, BGP
Features
Power Supply
From the network
Maximum number of VLANs
255 ×
Features
IPv6 Ready
Dimensions
Width
326 mm
Height
382 mm
Depth
88 mm
Material
Body material
Plastic
Operating temperature
Minimum operating temperature
-20 °C
Maximum operating temperature
65 °C
