Type
Switch type
Centrally controlled by controller
Design
Rack
Use
Company
Functions
Switching layer
L3
Advanced network functions
QoS (Quality of Service), VLAN, LACP line aggregation
Ports
RJ-45
48 ×
SFP+
4 ×
10/100/1000Base-T
48
LAN port transmission speed
Number of LAN ports with 1 Gbit speed
48
Number of LAN ports with 10 Gbit speed
4
Features
Power Supply
From the network
Speed
Switching capacity
176 Gb/s
Packet capacity (64B packets, in million of packets)
130.94 Mpps
Dimensions
Width
442.4 mm
Height
43.7 mm
Depth
285.4 mm
Material
Body material
Metal
Operating temperature
Minimum operating temperature
-5 °C
Maximum operating temperature
40 °C
Weight
Weight
4,000 g
